分断能力：
250V交流电时为1500A（1A-10A）
材料：
保险丝体-玻璃管
端盖——镀镍黄铜
尾纤——镀镍黄铜盖上的镀锡铜
工作温度：
-40°C~+125°C
焊接条件：
波峰焊：260℃，≤5S
手工焊：360℃，≤1S
电气特性：
| 电气特性 | ||
| 测试电流 | 熔断时间 | |
| 最小 | 最大 | |
| 150% | 1 hour | - |
| 210% | 100ms | 1800s |
| 275% | 250ms 750ms | 80s(250mA-800mA) 80s(1A-20A) |
| 400% | 50ms 95ms 150ms | 5s(250mA-800mA) 5s(1A-3.15A) 5s(4A-20A) |
| 1000% | 5ms 10 ms | 150ms(250mA-3.15A) 150ms(4A-20A) |
Approvals认证：
○ 表示认证中Pending ● 表示已获认证Approvals
| Current Rating | Voltage Rating | Norminal Melting I2T(A2sec) | Approvals 认证 | ||||
| 额定电流 | 额定电压 |  |  |  |  |  | |
| 250mA | 250V | 0.047 | ● | ● | ● | ||
| 315mA | 250V | 0.075 | ● | ● | ● | ||
| 400mA | 250V | 0.121 | ● | ● | ● | ||
| 500mA | 250V | 0.212 | ● | ● | ● | ||
| 630mA | 250V | 0.336 | ● | ● | ● | ||
| 800mA | 250V | 1.425 | ● | ● | ● | ||
| 1A 250V | 250V | 2.227 | ● | ● | ● | ● | |
| 1.25A | 250V | 2.888 | ● | ● | ● | ● | |
| 1.6A | 250V | 4.547 | ● | ● | ● | ● | |
| 2A | 250V | 8.855 | ● | ● | ● | ● | |
| 2.5A | 250V | 14.81 | ● | ● | ● | ● | |
| 3.15A | 250V | 32.22 | ● | ● | ● | ● | |
| 4A | 250V | 45.22 | ● | ● | ● | ● | |
| 5A | 250V | 79.89 | ● | ● | ● | ● | |
| 6.3A | 250V | 120.18 | ● | ● | ● | ● | |
| 8A | 250V | 165.53 | ● | ● | ● | ● | |
| 10A | 250V | 268.91 | ● | ● | ● | ● | |
| 12.5A | 250V | 420.16 | ○ | ○ | ● | ● | |
| 15A | 250V | 707.42 | ● | ● | |||
| 16A | 250V | 963.31 | ○ | ○ | ● | ||
| 20A | 250V | 1579.05 | ○ | ○ | ● | ||
