分断能力：
在125V/250V交流电（200mA-6.3A）下为50安培
材料：
保险丝体-玻璃管
端盖——镀镍黄铜
尾纤——镀镍黄铜盖上的镀锡铜
工作温度：
-40°C~+125°C
焊接条件：
波峰焊：260℃，≤5S
手工焊：360℃，≤1S
电气特性：
| 电气特性 | ||
| 测试电流 | 熔断时间 | |
| 最小 | 最大 | |
| 100% | 4 hour | - |
| 200% | 100ms | 60s |
Approvals认证：
○ 表示认证中Pending ● 表示已获认证Approvals
| 额定电流 | 额定电压 | I2T(A2sec) | 认证 | |
 |  | |||
| 200mA | 125V/250V | 0.11 | ● | ● |
| 250mA | 125V/250V | 0.14 | ● | ● |
| 300mA | 125V/250V | 0.2 | ● | ● |
| 315mA | 125V/250V | 0.23 | ● | ● |
| 350mA | 125V/250V | 0.27 | ● | ● |
| 400mA | 125V/250V | 0.38 | ● | ● |
| 500mA | 125V/250V | 0.5 | ● | ● |
| 600mA | 125V/250V | 0.72 | ● | ● |
| 630mA | 125V/250V | 0.9 | ● | ● |
| 750mA | 125V/250V | 1.2 | ● | ● |
| 800mA | 125V/250V | 1.6 | ● | ● |
| 1A | 125V/250V | 2.4 | ● | ● |
| 1.25A | 125V/250V | 3.5 | ● | ● |
| 1.5A | 125V/250V | 4 | ● | ● |
| 2A | 125V/250V | 7.2 | ● | ● |
| 2.5A | 125V/250V | 9.6 | ● | ● |
| 3A | 125V/250V | 16 | ● | ● |
| 3.15A | 125V/250V | 17.8 | ● | ● |
| 3.5A | 125V/250V | 22 | ● | ● |
| 4A | 125V/250V | 28 | ● | ● |
| 5A | 125V/250V | 45 | ● | ● |
| 6A | 125V/250V | 62 | ● | ● |
| 6.3A | 125V/250V | 70 | ● | ● |
| 6.3A | 125V/250V | 35.99 | ● | ● |
