产品参数
| 分断能力 | 材料 | 工作温度 |
| 400V AC/DC（100mA-10A）时为2KA安培 | Fuse body -- ceramic tude | -40℃～+125℃ |
| 500V AC/DC（100mA-20A）时为500A安培 | End -- Sliver plated brass | |
| 600V AC/DC（100mA-20A）时为300A安培 | Pigtail -- tin plated copper on nickel plated brass cap |
电气特性
| 测试电流 | 熔断时间 | |
| Min最小 | Max最大 | |
| 150% | 1 hours | - |
| 210% | 100ms | 1800m |
| 1000% | 10ms | 150ms |
Approvals认证（○ Pending表示认证中 ● Approvals表示已获认证）
| 额定电流 | 额定电压 | 12T(A2sec) | 认证 | ||||
 |  |  |  |  | |||
| 100mA | 400V/500V/600V | 0.0068 | ○ | ○ | ● | ○ | ○ |
| 125mA | 400V/500V/600V | 0.0107 | ○ | ○ | ● | ○ | ○ |
| 160mA | 400V/500V/600V | 0.0165 | ○ | ○ | ● | ○ | ○ |
| 200mA | 400V/500V/600V | 0.0281 | ○ | ○ | ● | ○ | ○ |
| 250mA | 400V/500V/600V | 0.0432 | ○ | ○ | ● | ○ | ○ |
| 315mA | 400V/500V/600V | 0.0644 | ○ | ○ | ● | ○ | ○ |
| 400mA | 400V/500V/600V | 0.0947 | ○ | ○ | ● | ○ | ○ |
| 500mA | 400V/500V/600V | 0.1954 | ○ | ○ | ● | ○ | ○ |
| 630mA | 400V/500V/600V | 0.3132 | ○ | ○ | ● | ○ | ○ |
| 800mA | 400V/500V/600V | 0.9094 | ○ | ○ | ● | ○ | ○ |
| 1A | 400V/500V/600V | 1.966 | ○ | ○ | ● | ○ | ○ |
| 1.25A | 400V/500V/600V | 2.754 | ○ | ○ | ● | ○ | ○ |
| 1.6A | 400V/500V/600V | 4.421 | ○ | ○ | ● | ○ | ○ |
| 2A | 400V/500V/600V | 8.563 | ○ | ○ | ● | ○ | ○ |
| 2.5A | 400V/500V/600V | 14.5 | ○ | ○ | ● | ○ | ○ |
| 3.15A | 400V/500V/600V | 30.42 | ○ | ○ | ● | ○ | ○ |
| 4A | 400V/500V/600V | 43.88 | ○ | ○ | ● | ○ | ○ |
| 5A | 400V/500V/600V | 74.62 | ○ | ○ | ● | ○ | ○ |
| 6.3A | 400V/500V/600V | 116.69 | ○ | ○ | ● | ○ | ○ |
| 8A | 400V/500V/600V | 157.89 | ○ | ○ | ● | ○ | ○ |
| 10A | 400V/500V/600V | 262.38 | ○ | ○ | ● | ○ | ○ |
| 12.5A | 400V/500V/600V | 420.16 | ○ | ○ | ● | ○ | ○ |
| 15A | 400V/500V/600V | 681.07 | ○ | ○ | ● | ○ | ○ |
| 16A | 400V/500V/600V | 944.78 | ○ | ○ | ● | ○ | ○ |
| 20A | 400V/500V/600V | 1500.58 | ○ | ○ | ● | ○ | ○ |
